Bielda AC Series Hydraulic Sheet Bending Press

MAIN CONFIGURATION

The Bielda AC Series represents the technological pinnacle of BIELDA hydraulic sheet bending presses.

Designed by our engineers to meet any challenge, the Bielda AC press stands out for its ability to deliver high performance where production environments require small volumes and a wide variety of products.

Carefully selected components, a robust steel frame, and a wide range of standard equipment such as 2 Servo Axes (X, R), long-length bending compensation, quick tool changes for full length, and various configuration options make the Bielda AC the ideal choice for complex part production.

When machine setup and programming times are critical for operators, the solution comes from the Bielda AC Series with a control system that has an easy-to-use interface, shortening programming and program loading times.

• 4 axes: Y1, Y2, X, R.
• 300 mm stroke, exceptionally high.
• 500 mm throat, exceptionally large.
• Delem 58T control (touchscreen, machine, part, and tool visualization, back gauge with offline programming software Profile TL, up to 4 axes).
• ESA 675 control with 3D color graphic display (19-inch TFT Windows) with offline software.
• Cybelec 15T system, 15” 2D color touchscreen with automatic bending sequence calculation.
• Manual WILA ‘opposing wave’ frame deflection system.
• High-efficiency pump for low energy consumption.
• Original Hoerbiger Bosch Rexroth hydraulic system, CE-compliant.
• Schneider-Siemens electrical components mounted in ventilated cabinet.
• Multifunctional control system with control panel and pedal, CE standard.
• Linear optical scale with high precision ±0.005 mm
• High descent speed (up to 120 mm/s).
• High lift speed (up to 120 mm/s).
• Complete electrical panel and components for 400V three-phase 50Hz.
• Sliding front arms.
• Robust CNC-controlled back gauges.
• Back gauges controlled by servo motors and high-precision drivers.
• X axis stroke 750 mm
• Back gauge manually movable along full length
• Side protections
• Promecam tool clamping system
• Hardened lower tools 835 mm length, 60×60 mm, 4V 16/22/35/50 mm (2067)
• Standard upper tools 835 mm length, 66.6 mm (1260)-105 mm (1281) (>400t)
• Narrow or wide table with T-slot

OPTIONAL CONFIGURATION

• Delem 66T control with 2D touchscreen or Delem 69T with 3D color touchscreen, offline T3D programming, and DXF import package.
• VisiTouch 19, Windows 19” 3D, software package (DXF) – DXF 3D import format.
• Motorized WILA ‘opposing wave’ frame deflection system.
• Axis systems: – 4 rear axes X, R, Z1+Z2 – 5 rear axes X1+X2, R, Z1+Z2 – 6 rear axes X1+X2, R1+R2, Z1+Z2
• X axis extended to 1000 mm.
• AKAS finger protection system and safety PLC (CE).
• DSP finger protection system and safety PLC (non-CE).
• Front light barriers (for tandem applications).
• Additional back gauge.
• Additional front arms.
• Green Collection – energy saving.
• Hydraulic or mechanical WILA upper tool clamping system.
• Hydraulic or mechanical WILA lower tool clamping system.
• Promecam hydraulic upper tool clamping.
• Tool clamping system compatible with American tools.
• AP3+AP4 axis for CNC-controlled sheet tracking arm.
• Table with T-slot.
• Heat exchanger (oil cooling).
• Oil heating unit.
• Additional control panel and pedal.
• ROL1 or ROL200-ROL4 for upper tool clamping.
• Custom stroke, custom throat size.
• Operating voltage 220-240V 60Hz or 440-480V 60Hz
• Operating voltage 220-240V 60Hz and 440-480V 60Hz dual operation possible
