Lathe Bielda B35Y – 60-200T

The hydraulic machine Bielda B35Y from the 60-200T series features a hydraulic drive system and is a state-of-the-art product from China. The machine is known for low noise, smooth operation, simple structure, and ease of use.
It can cut, punch, and notch various materials: metal plates, square bars, round bars, angle profiles, T-Bar, I-Bar, and metal channels.

Main Functions

• Notching: The positioning ruler on the worktable allows making slots at 90° and 45° in various sizes.
• Channel cutting: The quantity and size of round or square holes can be customized according to client requirements.
• Punching: Various die and punch sizes available; the client can choose the desired type.
• Angle cutting: The machine can cut any size of angle profiles, T-Bar, I-Bar, and metal channels within the maximum capacity.
• Flat profile cutting: The positioning ruler controls the shape and length of the cut with high accuracy.

Technical Specifications – B35Y 60-200T Series

Processable Bars and Angles

• Round bars: 45–70 mm
• Square bars: 40×40 – 60×60 mm
• 90° angles: 125×125×12 – 200×200×18 mm
• 45° angles: 70×70×8 – 80×80×10 mm
• T-Bar 90°: 120×120×12 – 200×200×18 mm
• T-Bar 45°: 60×60×8 – 80×80×10 mm
• I-Bar: 126×74×5 – 280×124×10.5 mm
• Channels: 126×53×5.5 – 300×89×11.5 mm

The Bielda B35Y is ideal for metalworking factories and workshops, providing high performance, precision, and ease of operation for cutting, punching, and notching various metal profiles.
